• High flow pump
• Max. pressure: 0,6 bar
• Max. flow: 20 m³/h

Technical features

• Polypropylene pump body
• Capacitor integrated into the terminal box
• Self draining
• 3 outlet positions
• 3 terminal box positions
• Single and three phase voltages 50Hz or 60 Hz
• Single-speed, two-speed or multi-speed

Performances

• 560 W motor: Max. flow 10 m³/h at 0,5 bar. Max. pressure: 0,5 bar
• 900 W motor: Max. flow 11,5 m³/h at 1 bar. Max. pressure: 1,7 bar
• 1150 W motor: Max. flow 16,5 m³/h at 0,3 bar. Max. pressure: 1,7 bar
• 1350 W motor: Max. flow 19 m³/h at 0,1 bar. Max. pressure: 1,7 bar

Consult he technical date sheet curves to know the flow rate depending on the chosen operating point.

Complies with Standards

• 2004/108/EC
• EN 60 335-1
• EN 60 335-2-41

Applications

• Pump for whirlpool baths with strong capacity
• Pump created for electronic variation
